Ethernet MAC Registers

Ethernet MAC registers (0xFFC0 3000 – 0xFFC0 31FF) are listed in
Table A-21.
Table A-21. Ethernet MAC Registers
Memory-mapped
Address
0xFFC0 3000
0xFFC0 3004
0xFFC0 3008
0xFFC0 300C
0xFFC0 3010
0xFFC0 3014
0xFFC0 3018
0xFFC0 301C
0xFFC0 3020
0xFFC0 3024
0xFFC0 302C
0xFFC0 3030
0xFFC0 3034
0xFFC0 3038
ADSP-BF537 Blackfin Processor Hardware Reference
Register Name
EMAC_OPMODE
EMAC_ADDRLO
EMAC_ADDRHI
EMAC_HASHLO
EMAC_HASHHI
EMAC_STAADD
EMAC_STADAT
EMAC_FLC
EMAC_VLAN1
EMAC_VLAN2
EMAC_WKUP_CTL
EMAC_WKUP_
FFMSK0
EMAC_WKUP_
FFMSK1
EMAC_WKUP_
FFMSK2
System MMR Assignments
See Page
"MAC Operating Mode Register" on
page 8-64
"MAC Address Low Register" on page 8-71
"MAC Address High Register" on page 8-71
"MAC Multicast Hash Table Low Register" on
page 8-74
"MAC Multicast Hash Table High Register"
on page 8-75
"MAC Station Management Address Register"
on page 8-76
"MAC Station Management Data Register" on
page 8-78
"MAC Flow Control Register" on page 8-79
"MAC VLAN1 Tag Register" on page 8-81
"MAC VLAN2 Tag Register" on page 8-81
"MAC Wakeup Frame Control and Status
Register" on page 8-82
"MAC Wakeup Frame0 Byte Mask Register"
on page 8-85
"MAC Wakeup Frame1 Byte Mask Register"
on page 8-86
"MAC Wakeup Frame2 Byte Mask Register"
on page 8-87
