General Specifications - Basler BE1-11g Instruction Manual

584 9424200994 Rev U
BESTlogic™Plus
Update Rate .............................................................. ¼ cycle

General Specifications

AC Current Inputs
5 Ampere CT
Continuous Rating ..................................................... 20 A
One Second Rating ................................................... 400 A
½
For other current levels, use the formula: I= (K/t) where t = time in seconds, K = 160,000.
Begins to Clip (Saturate) ........................................... 150 A
Burden ....................................................................... <10 mΩ
1 Ampere CT
Continuous Rating ..................................................... 4 A
One Second Rating ................................................... 80 A
½
For other current levels, use the following formula: I = (K/t) where t = time in seconds, K = 6,400.
Begins to Clip (Saturate) ........................................... 30 A
Burden ....................................................................... <10 mΩ
SEF
Continuous Rating ..................................................... 4 A
One Second Rating ................................................... 80 A
Begins to Clip (Saturate) ........................................... 7.5 A
Burden ....................................................................... <22 mΩ
Terminals (CT1)
IA1 ............................................................................. D1, D2
IB1 ............................................................................. D3, D4
IC1 ............................................................................. D5, D6
IN1 ............................................................................. D7, D8
Terminals (CT2) (Optional)
IA2 ............................................................................. F1, F2
IB2 ............................................................................. F3, F4
IC2 ............................................................................. F5, F6
IN2 ............................................................................. F7, F8
Phase AC Voltage Inputs
Continuous Rating ..................................................... 300 V, Line to Line
One Second Rating ................................................... 600 V, Line to Neutral
Burden ....................................................................... <1 VA @ 300 Vac
Terminals
VA .............................................................................. C13
VB .............................................................................. C14
VC ............................................................................. C15
N ................................................................................ C16
Auxiliary AC Voltage Input
Continuous Rating ..................................................... 150 V, Line to Line
One Second Rating ................................................... 600 V, Line to Neutral
Burden ....................................................................... <1 VA @ 150 Vac
Terminals................................................................... C17, C18
Specifications BE1-11g
