Output Test (25A Voltage Monitor)
Step 1: With no voltage applied to either the Line or Auxiliary voltage sources, OUT7 should be closed.
This verifies the DEAD-LINE, DEAD AUX output of 25 Voltage Monitor.
Step 2: Increase the Line VTP voltage above the DEAD-LINE setting and verify that OUT7 opens.
Continue increasing voltage until OUT7 closes when the LIVE-LINE setting is exceeded. This
verifies the LIVE-LINE, DEAD-AUX output of 25A Voltage Monitor. Remove voltage source 1.
Step 3: Increase the Auxiliary VTX voltage above the DEAD-LINE setting and verify that OUT7 opens.
Continue increasing voltage until OUT7 closes when the LIVE-LINE setting is exceeded. This
verifies the DEAD-LINE, LIVE-AUX output of 25A Voltage Monitor.
Step 4: (Optional.) Repeat Steps 1 through 3 for Settings Group 1, 2, and 3.

Voltage Monitor Functional Test Report

VTP and VTX Live Voltage, Dead Voltage Pickup Test (25A Voltage Monitor)
Accuracy = ±2%
Step
6 VTP - Dead V Dropout - 55.0 V
7 VTP - Live V Pickup - 90.0 V
9 VTX - Dead V Dropout - 55.0 V
10 VTX - Live V Pickup - 90.0 V
Live/Dead Dropout Timing Verification (25A Voltage Monitor)
Accuracy = ±0.5% or ±2 cycles, whichever is greater
Step Dropout Delay Setting
4 VTP - Dead V Dropout Delay - 50 ms
5 VTP - Live V Dropout Delay - 50 ms
6 VTP - Dead V Dropout Delay - 2,000 ms
6 VTP - Live V Dropout Delay - 2,000 ms
6 VTP - Dead V Dropout Delay - 5,000 ms
6 VTP - Live V Dropout Delay - 5,000 ms
7 VTX - Dead V Dropout Delay - 50 ms
7 VTX - Live V Dropout Delay - 50 ms
7 VTX - Dead V Dropout Delay - 2,000 ms
7 VTX - Live V Dropout Delay - 2,000 ms
7 VTX - Dead V Dropout Delay - 5,000 ms
7 VTX - Live V Dropout Delay - 5,000 ms
Synchronizer (25A) Test
Setting Low Actual
53.9 V
89.2 V
53.9 V
89.2 V
Low Actual Timing
18 ms
18 ms
1,968 ms
1,968 ms
4,968 ms
4,968 ms
18 ms
18 ms
1,968 ms
1,968 ms
4,968 ms
4,968 ms
9424200994 Rev U
High Pass/Fail
56.1 V P / F
91.8 V P / F
56.1 V P / F
91.8 V P / F
High Pass/Fail
82 ms P / F
82 ms P / F
2,032 ms P / F
2,032 ms P / F
5,032 ms P / F
5,032 ms P / F
82 ms P / F
82 ms P / F
2,032 ms P / F
2,032 ms P / F
5,032 ms P / F
5,032 ms P / F
