Basler BE1-11g Instruction Manual page 421

9424200994 Rev U
Step Dropout Delay Setting
6 VTP - Dead V Dropout Delay - 5000 ms
6 VTP - Live V Dropout Delay - 5000 ms
7 VTX - Dead V Dropout Delay - 50 ms
7 VTX - Live V Dropout Delay - 50 ms
7 VTX - Dead V Dropout Delay - 2000 ms
7 VTX - Live V Dropout Delay - 2000 ms
7 VTX - Dead V Dropout Delay - 5000 ms
7 VTX - Live V Dropout Delay - 5000 ms
Sync-Check Verification (25)
Voltage Difference Accuracy = ±2% or ±1 V, whichever is greater
Step Voltage Difference Setting
5 VTX - Voltage Difference = 10%
6 VTP - Voltage Difference = 10%
Slip Angle Accuracy = ±1°
Step Slip Angle Setting
7 Slip Angle = +10°
7 Slip Angle = –10°
Slip Frequency Accuracy = ±0.01 Hz
Step Slip Frequency Setting
VTP - Slip Frequency =
8
59.70 Hz
VTP - Slip Frequency =
8
60.30 Hz
VTX - Slip Frequency =
9
59.70 Hz
VTX - Slip Frequency =
9
60.30 Hz
BE1-11g
Low Actual Timing
4,968 ms
4,968 ms
18 ms
18 ms
1,968 ms
1,968 ms
4,968 ms
4,968 ms
Actual
Low
Pickup
107.8 V
107.8 V
Actual
Low
Pickup
9°
–9°
Actual
Low
Pickup
58.50 Hz
59.09 Hz
58.50 Hz
59.09 Hz
High
5,032 ms
5,032 ms
82 ms
82 ms
2,032 ms
2,032 ms
5,032 ms
5,032 ms
Actual
High
Dropout
112.2 V
112.2 V
Actual
High
Dropout
11°
–11°
Actual
High
Dropout
60.89 Hz
61.50 Hz
60.89 Hz
61.50 Hz
Sync-Check (25) Test
409
Pass/Fail
P / F
P / F
P / F
P / F
P / F
P / F
P / F
P / F
Pass/Fail
P / F
P / F
Pass/Fail
P / F
P / F
Pass/Fail
P / F
P / F
P / F
P / F
