2 Harmonic Restraint Verification (Independent)
Pickup Accuracy = ±2% or ±0.05A, whichever is greater.
Step Pickup Setting
5 0.24 A
nd
2 Harmonic Restraint Verification (Shared)
Pickup Accuracy = ±2% or ±0.05A, whichever is greater.
Step Pickup Setting
5 3 x (0.08) A
th
5 Harmonic Restraint Verification (Independent)
Pickup Accuracy = ±2% or ±0.05A, whichever is greater.
Step Pickup Setting
5 0.24 A
th
5 Harmonic Restraint Verification (Shared)
Pickup Accuracy = ±2% or ±0.05A, whichever is greater.
Step Pickup Setting
5 3 x (0.23) A
BE1-11g
Low Actual Pickup
0.19 A
Low Actual Pickup
3x (0.06) A
Low Actual Pickup
0.19 A
Low Actual Pickup
3x (0.22) A
High Pass/Fail
0.29 A P / F
High Pass/Fail
3 x (0.10) A
High Pass/Fail
0.29 A P / F
High Pass/Fail
3 x (0.25) A
Phase Current Differential (87) Test
