Bestcomsplus Settings Loader Tool Settings - Basler BE1-11g Instruction Manual

678 9424200994 Rev U
Bar Code Reader and Bar Codes
The BESTCOMSPlus Settings Loader Tool is compatible with bar code readers which conform to
UnifiedPOS specifications. Bar code readers and bar code labels are not provided and must be acquired
separately. Refer to the bar code reader's documentation for installation instructions.
Any bar code compatible with your bar code reader may be used.
®
BESTCOMSPlus Settings Loader Tool Settings
BESTCOMSPlus Settings Loader Tool settings are found on two main screens, the Loader Grid and
Configuration screen. The Loader Grid contains management options for the product settings files and
their associated bar codes. The Configuration screen contains product-specific options for the default
behavior of the BESTCOMSPlus Settings Loader Tool. These settings are described in the following
paragraphs.
Loader Grid
One entry, or row, in the Loader Grid contains all of the necessary data to associate a product settings file
with a bar code. New entries can be added. Existing entries can be edited, deleted, and uploaded to a
Basler product.
Figure 410. Loader Grid
Scanning Bar Codes
Place the cursor in the text field, found at the top of the Loader Grid screen, and scan a bar code. If
successful, the digits which comprise the bar code appear in the text field. The BESTCOMSPlus Settings
Loader Tool automatically searches for this bar code among the entries in the Loader Grid and displays
the matching entry. Click Clear to remove the digits from the text field.
Adding an Entry
®
Click Add to create an entry. The BESTCOMSPlus Settings Loader Tool: Add Device dialog box appears
(Figure 411).
BESTCOMSPlus® Settings Loader Tool BE1-11g
