Step 4: Gradually decrease the magnitude of all three phase voltages until OUT2 closes. Record the
time to trip (OUT1 closes). Verify that the 21-1-AB, 21-1-BC, and 21-1-CA targets are displayed
on the front-panel display. Increase the voltage until OUT2 opens. Reset the target.
Step 5: Repeat step 4 for the time delays in the second and third rows of Table 236. Record the results.
Timing accuracy is 0.5% or 2 cycles, whichever is greater.
Step 6: (Optional.) Repeat steps 1 through 5 for settings group 1, 2, and 3.
Step 7: (Optional.) Repeat steps 1 through 6 for 21-2.

Functional Test Report

Pickup Verification Table 2 Row 1
Diameter Setting Range = 0 – 500 secondary Ω
Pickup Accuracy = ±2% or ±0.1 Ω, whichever is greater
Reset Hysteresis = 105% of the diameter setting
Reset Accuracy = ±2% or ±0.1 Ω, whichever is greater
Step Pickup Setting
6 45.28 Vpn
Pickup Verification Table 2 Row 2
Step Pickup Setting
6 42.71 Vpn
Pickup Verification Table 2 Row 3
Step Pickup Setting
6 4.34 Vpn
Timing Verification
Time Delay Range = 0 to 300,000 ms
Timing Accuracy = ±0.5% or ±2 cycles, whichever is greater
Step Time Delay Setting
4 100 ms
5 60,000 ms
5 0 ms
BE1-11g
Low Actual Pickup
43.71 V
Low Actual Pickup
41.23 V
Low Actual Pickup
3.84 V
Low
83.3 ms
57,000 ms
>0 ms
High Low Actual Reset
46.85 V 46.26 V
High Low Actual Reset
44.19 V 48.72 V
High Low Actual Reset
4.84 V 5.86 V
Actual Timing
High Pass/Fail
48.15 V P / F
High Pass/Fail
50.44 V P / F
High Pass/Fail
7.59 V P / F
High Pass/Fail
117 ms P / F
63,000 ms P / F
33.3 ms P / F
Distance (21) Test
