Basler BE1-11g Instruction Manual page 653

9424200994 Rev U
Maximum screw torque is 5 inch-pounds (0.56 N•m) for the 12- and 15-position connectors. Maximum
screw torque is 9 inch-pounds (1.01 N•m) for the 6-position connector.
Operating Power
The RTD module operating power input accepts 125/250 Vac/dc and tolerates voltage over the range of
90 to 270 Vac or 90 to 300 Vdc. The operating power inputs are not polarity sensitive. Operating power
terminals are listed in Table 259.
Terminal
TB1-1
TB1-2
TB1-3
Alarm Contacts
These terminals provide form C (SPDT) alarm contacts. Alarm contact terminals are listed in Table 260.
Terminal
TB1-4
TB1-5
TB1-6
RTD Module Inputs and Outputs
Input and output terminals are shown in Figure 387 and listed in Table 261.
BE1-11g
Table 259. Operating Power Terminals
Operating power input
Operating power input
Chassis ground connection
Table 260. Alarm Contact Terminals
Normally Open
Common
Normally Closed
Description
Description
641
RTD Module
