Timing Verification (Vx Fundamental Mode)
Time Delay Range = 50 to 600,000 ms
Timing Accuracy = ±0.5% or ±2 cycles, whichever is greater
Step Time Delay Setting
4 2,000 ms
5 5,000 ms
5 10,000 ms
Pickup Verification (Vx Third Harmonic Mode)
Pickup Setting Range = 1 to 150 V
Pickup Accuracy = ±2% or ±1 V, whichever is greater
Reset/Pickup Ratio = 102% ±1%
Step Pickup Setting
6 115.0 V
7 65.0 V
7 20.0 V
* Reset range is calculated from the pickup setting and may need adjusted based on actual pickup.
Timing Verification (Vx Third Harmonic Mode)
Time Delay Range = 50 to 600,000 ms
Timing Accuracy = ±0.5% or ±2 cycles, whichever is greater
Step Time Delay Setting
4 2,000 ms
5 5,000 ms
5 10,000 ms
Auxiliary Undervoltage (27X) Test
Low
1,968 ms
4,968 ms
9,950 ms
Low Actual Pickup
112.7 V
63.7 V
19.0 V
Low
1,968 ms
4,968 ms
9,950 ms
Actual Timing
High Low* Actual Reset
117.3 V 116.1 V
66.3 V 65.6 V
21.0 V 20.2 V
Actual Timing
9424200994 Rev U
High Pass/Fail
2,032 ms P / F
5,032 ms P / F
10,050 ms P / F
High* Pass/Fail
118.4 V P / F
66.9 V P / F
20.6 V P / F
High Pass/Fail
2,032 ms P / F
5,032 ms P / F
10,050 ms P / F
