Basler BE1-11g Instruction Manual page 93

9424200994 Rev U
Setting
Mode*
Pickup
Timing Mode
Time Delay (Definite
Timing)
Time Dial (Inverse
Timing)
Curve
Reset Timing
A Constant
B Constant
C Constant
N Constant
R Constant
* To use 3V0, V1, or V2, the VTP connection cannot be single-phase.
BE1-11g
Figure 55. Auxiliary Overvoltage Settings Screen
Table 27. Operational Settings
Range
Disabled,
3V0, V1, V2,
Vx Fundamental,
Vx Third Harmonic
0 or 1 to 150
Definite or Inverse
50 to 600,000
0 to 9.9
P, T1, T2, T3, or T4
Integrating or
Instantaneous
0 to 600
0 to 25
0 to 1
0.5 to 2.5
0 to 30
Unit of
Increment
Measure
n/a n/a
0.1
volts
secondary
n/a n/a
varies milliseconds
0.1 units
n/a n/a
n/a n/a
0.00001 A Constant
0.00001 B Constant
0.00001 C Constant
0.00001 N Constant
0.00001 R Constant
Auxiliary Overvoltage (59X) Protection
81
Default
Disabled
0
Definite
50
0
P
Instantaneous
1.00000
0.00000
1.00000
1.00000
0.00000
