Functional Test Report - Basler BE1-11g Instruction Manual

9424200994 Rev U
Step 2: Prepare to monitor the 59P-1 timings. Timing accuracy is verified by measuring the elapsed
time between a sensing voltage change and OUT1 closing.
Step 3: Connect and apply a 120 Vac, three-phase voltage source to terminals C13 (A-phase), C14 (B-
phase), C15 (C-phase), and C16 (Neutral).
Step 4: Step the A-phase voltage up to 130 volts. Measure the time delay and record the result.
Step 5: Repeat step 4 for the 5,000 ms and 10,000 ms time delay settings of Table 161. Record the
results.
Step 6: (Optional.) Repeat steps 1 through 5 for the B-phase and C-phase voltage inputs. Note: Be sure
to enable proper target for each phase being tested.
Step 7: (Optional.) Repeat steps 1 through 6 for settings group 1, 2, and 3.
Step 8: (Optional.) Repeat steps 1 through 7 for 59P-2, 59P-3, and 59P-4.

Functional Test Report

Pickup Verification
Pickup Setting Range = 1 to 300 V
Pickup Accuracy = ±2% or ±1 V, whichever is greater
Dropout/Pickup Ratio = 98% ±1%
Step Pickup Setting
6 245.0 V
7 125.0 V
7 75.0 V
* Dropout range is calculated from the pickup setting and may need adjusted based on actual pickup.
Timing Verification
Time Delay Range = 50 to 600,000 ms
Timing Accuracy = ±0.5% or ±2 cycles, whichever is greater
Step Time Delay Setting
4 2,000 ms
5 5,000 ms
5 10,000 ms
BE1-11g
Low Actual Pickup
240.1 V
122.5 V
73.5 V
Low
1,968 ms
4,968 ms
9,950 ms
High Low* Actual Dropout
249.9 V 237.6 V
127.5 V 121.3 V
76.6 V 72.8 V
Actual Timing
Pass/Fail
High*
242.5 V P / F
123.8 V P / F
74.3 V P / F
High Pass/Fail
2,032 ms P / F
5,032 ms P / F
10,050 ms P / F
Phase Overvoltage (59P) Test
429
