Functional Test Report - PLL

ΔV Accuracy = ±2% or ±1V, whichever is greater.
Slip Freq Accuracy = ±0.01Hz
Min/Max Slip Accuracy = ±0.01Hz
Breaker Close Angle Accuracy = ±1°
Test Setting
ΔV Increasing
15% (79.67 V)
ΔV Decreasing
15% (58.89 V)
Slip Freq
0.5 Hz
Increasing
Slip Freq
0.5 Hz
Decreasing
Breaker Close
Angle
Increasing (AΦ)
Breaker Close
Angle
Decreasing
(AΦ)
Synchronizer (25A) Test
Figure 330. BESTlogicPlus Settings 2 (25A)
Low
78.67 V
57.89 V
60.49 Hz
59.49 Hz
20° 19°
–19°
20°
Actual High
80.67 V
59.89 V
60.51 Hz
59.51 Hz
21°
–21°
9424200994 Rev U
Pass/Fail
P / F
P / F
P / F
P / F
P / F
P / F
BE1-11g
