Menu Item
Tile
Maximize All
Help
Check for Updates
Check for Update Settings
About
Lower Menu Bar (BE1-11 Plugin)
Lower menu bar functions are listed and described in Table 102.
Menu Button

Settings Explorer

The Settings Explorer is a convenient tool within BESTCOMSPlus used to navigate through the various
settings screens of the BE1-11 plugin. Descriptions of these configuration settings are organized as
follows:
•
General Settings
•
Communications
BE1-11g
Tile horizontally or vertically
Maximize all windows
Check for BESTCOMSPlus updates via the internet
Enable or change automatic checking for updates
View general, detailed build, and system information
Table 102. Lower Menu Bar (BE1-11 Plugin)
Enables you to show/hide the Metering Panel, Settings Panel, or Settings
Info Panel.
Opens and saves workspaces. Customized workspaces make switching
between tasks easier and more efficient.
Opens a saved settings file.
Opens the BE1-11 Connection screen which enables you to connect to
the BE1-11g via USB or Ethernet. This button appears only when a
BE1-11g is not connected.
Used to disconnect a connected BE1-11g. This button appears only
when a BE1-11g is connected.
Displays the Print Preview screen where a preview of the Metering
printout is shown. Click on the printer button to send to a printer.
Enables all metering values to be exported into a *.csv (comma-
separated values) file.
A pull-down menu allowing group selection is available when making
protection settings. The settings can be applied to Group 0, 1, 2, or 3. If a
global setting is being changed, Global will appear in place of the drop-
down menu.
Displays a drop-down list entitled Live Mode Settings which enables Live
mode where settings are automatically sent to the device in real time as
they are changed. The changed device settings are saved to non-volatile
memory by clicking on the Save button.
Saves all device settings to non-volatile memory. This button appears
only when operating in Live mode.
Sends settings to the BE1-11 when BESTCOMSPlus is not operating in
Live Mode. Click this button after making a setting change to send the
modified setting to the BE1-11g.
Description
Description
BESTCOMSPlus® Software
307
