Timing Verification (I2 Mode)
Time Delay Range = 0 to 60,000 ms
Timing Accuracy = ±0.5% or ±½ cycle, whichever is greater + 3 cycles max for currents 1.5 x pickup
Step Time Delay Setting
4 2,000 ms
5 5,000 ms
5 10,000 ms
Pickup Verification (IG Mode)
Pickup Setting Range = 0.5 to 150 A for 5A sensing
Pickup Accuracy =
Dropout should occur between 93-99% of the actual pickup value.
Step Pickup Setting
6 0.5 A (5A CT)
7 5.0 A (5A CT)
7 20.0 A (5A CT)
6 0.1 A (1A CT)
7 1.0 A (1A CT)
7 2.0 A (1A CT)
6 0.1 A (SEF)
7 1.0 A (SEF)
7 2.0 A (SEF)
* Dropout range is calculated from the pickup setting and may need adjusted based on actual pickup.
Timing Verification (IG Mode)
Time Delay Range = 0 to 60,000 ms
Timing Accuracy = ±0.5% or ±½ cycle, whichever is greater + 3 cycles max for currents 1.5 x pickup
Step Time Delay Setting
4 2,000 ms
5 5,000 ms
5 10,000 ms
Instantaneous Overcurrent (50) Test
Low
1,942 ms
4,927 ms
9,902 ms
0.1 to 30 A for 1A sensing
0.01 to 7.5 for SEF
±2% or ±50 mA, whichever is greater for 5A sensing
±2% or ±10 mA, whichever is greater for 1A sensing
±2.5% or ±2.5 mA, whichever is greater for SEF
Low Actual Pickup
0.45 A
4.9 A
20.6 A
0.09 A
0.98 A
1.96 A
0.09 A
0.85 A
1.95 A
Low
1,942 ms
4,927 ms
9,902 ms
Actual Timing
High Actual Dropout
Low*
0.55 A 0.465 A
5.1 A 4.65 A
20.4 A 18.6 A
0.11 A 0.093 A
1.02 A 0.93 A
2.04 A 1.86 A
0.11 A 0.093 A
1.15 A 0.93 A
2.05 A 1.86 A
Actual Timing
9424200994 Rev U
High Pass/Fail
2,058 ms P / F
5,073 ms P / F
10,098 ms P / F
Pass/Fail
High*
0.495 A P / F
4.95 A P / F
19.8 A P / F
0.099 A P / F
0.99 A P / F
1.98 A P / F
0.099 A P / F
0.99 A P / F
1.98 A P / F
High Pass/Fail
2,058 ms P / F
5,073 ms P / F
10,098 ms P / F
