Battery Replacement Procedure for H or P Style Case
Battery access is located on the right side of the BE1-11g on the digital circuit board. See Figure 275.
Step 1:
Remove the BE1-11g from service.
Step 2:
Remove the unit from the case.
Step 3:
Remove the old battery. Consult your local ordinance for proper battery disposal.
Step 4:
Insert the new battery with the "+" side facing up.
Step 5:
Insert the unit back into the case.
Step 6:
Return the BE1-11g to service.
Timekeeping
BE1-11
Protection
System
Relay
Minor
Power Trouble
Alarm
Edit
Select
Control
Switch
Figure 276. Re-Attaching the Front Cover
