Inverse Time Verification
Time Dial Range = 0.0 to 9.9
Timing Accuracy = ±5% or ±50 ms, whichever is greater
Time
Percent of
Step Dial
Nominal V/Hz
Setting
3 0.5 110%
3 0.5 120%
3 0.5 140%
4 1.0 110%
4 1.0 120%
4 1.0 140%
4 2.0 110%
4 2.0 120%
4 2.0 140%
Inverse Time Reset Verification
Time Dial Range = 0.0 to 9.9
Timing Accuracy = ±5% or ±50 ms, whichever is greater
Step Time Dial Setting
3 0.5
4 1.0
4 2.0
Definite Time Verification
Time Dial Range = 0 to 600,000
Timing Accuracy = ±0.5% or ±50 ms, whichever is greater
Step Time Delay Setting
3 500 ms
4 1,000 ms
4 5,000 ms
Overexcitation (24) Test
Actual
High
Pickup
2.41 V/Hz
Step Voltage Low
132 V 47.5 sec
144 V 11.875 sec
168 V 2.945 sec
132 V 95 sec
144 V 23.75 sec
168 V 5.985 sec
132 V 190 sec
144 V 47.5 sec
168 V 11.875 sec
Low Actual Timing
5.937 sec
11.875 sec
23.75 sec
Low
450 ms
950 ms
4,950 ms
Actual
Low*
Dropout
2.289 V/Hz
Actual Timing
High
6.562 sec
13.125 sec
26.25 sec
Actual Timing High
550 ms
1,050 ms
5,050 ms
9424200994 Rev U
High* Pass/Fail
2.336 V/Hz P / F
High Pass/Fail
52.5 sec P / F
13.125 sec P / F
3.255 sec P / F
105 sec P / F
26.25 sec P / F
6.615 sec P / F
210 sec P / F
52.5 sec P / F
13.125 sec P / F
Pass/Fail
P / F
P / F
P / F
Pass/Fail
P / F
P / F
P / F
BE1-11g
