Step 2: Prepare to monitor the 27P-1 timings. Timing accuracy is verified by measuring the elapsed
time between a sensing voltage change and OUT1 closing.
Step 3: Connect and apply a 120 Vac, three-phase voltage source to terminals C13 (A-phase), C14 (B-
phase), C15 (C-phase), and C16 (Neutral).
Step 4: Step the A-phase voltage down to 110 volts. Measure the time delay and record the result.
Step 5: Repeat step 4 for the 5,000 ms and 10,000 ms time delays of Table 143. Record the results.
Step 6: (Optional.) Repeat steps 1 through 5 for the B-phase and C-phase voltage inputs. Note: Be sure
to enable proper target for each phase being tested.
Step 7: (Optional.) Repeat steps 1 through 6 through 6 for settings group 1, 2, and 3.
Step 8: (Optional.) Repeat steps 1 through 7 for 27P-2, 27P-3, 27P-4, and 27P-5.

Functional Test Report

Pickup Verification
Pickup Setting Range = 1 to 300 V
Pickup Accuracy = ±2% or ±1 V, whichever is greater
Reset/Pickup Ratio = 102% ±1%
Step Pickup Setting
6 235.0 V
7 115.0 V
7 65.0 V
* Reset range is calculated from the pickup setting and may need adjusted based on actual pickup.
Timing Verification
Time Delay Range = 50 to 600000 ms
Timing Accuracy = ±0.5% or ±2 cycles, whichever is greater
Step Time Delay Setting
4 2,000 ms
5 5,000 ms
5 10,000 ms
BE1-11g
Low Actual Pickup
230.3 V
112.7 V
63.7 V
Low
1,968 ms
4,968 ms
9,950 ms
High Low* Actual Reset
239.7 V 237.3 V
117.3 V 116.1 V
61.2 V 65.6 V
Actual Timing
Phase Undervoltage (27P) Test
High* Pass/Fail
242.0 V P / F
118.4 V P / F
66.9 V P / F
High Pass/Fail
2,032 ms P / F
5,032 ms P / F
10,050 ms P / F
