Figure 411. Add Device Screen
Enter the name of the entry in the Name field. This appears in the first column of the Loader Grid.
Select the product type from the Type drop-down menu. This appears in the second column of the Loader
Grid.
Enter the bar code of the entry in the UPC Barcode field by placing the cursor in the UPC Barcode field
and scanning the bar code.
To select the product settings file for the entry, click the browse (...) button in the Location field. Use
standard Windows methods to navigate to the desired product settings file and click Open. Ensure that
the selected product type in the Type field matches that of the product settings file specified in the
Location field.
Click OK when finished.
Editing an Entry
To Edit an existing entry, select the entry in the Loader Grid and click Edit. The BESTCOMSPlus Settings
Loader Tool: Edit Device dialog box appears. The options are identical to those of the Add Device dialog.
When the desired changes have been made, click OK.
Deleting an Entry
To delete an entry from the Loader Grid, select the entry and click the Delete button. A prompt appears
providing the option to confirm or cancel the deletion.
Uploading an Entry
Select an entry and click Upload. A dialog appears which provides connection options for the appropriate
type of device. Refer to the Basler product instruction manual for detailed connection information. Once a
connection is established, the product settings associated with the entry are uploaded.
Configuration Settings
For configuration settings, click the Configure button in the bottom left of the Loader Grid. The product
tabs on the left represent the compatible Basler products. Each product tab contains tabs for Settings
Files and Connection Options. The options on these tabs are described below.
Setting Files Options
Use Saved Path: When enabled, the path specified in the Loader Grid entry is used when uploading the
settings file.
Single Folder: When enabled, this specifies a single folder which contains all settings files for the
product. The Windows filename specified in the Location field of the Loader Grid entry is searched for in
the Single Folder location. For example, all settings files for a product are located in "C:\Files". The
Location field in the Loader Grid entry for a device contains "C:\Documents\Settings\BE1-11
