Case cutout and drilling dimensions are shown in Figure 191.
0.655
0.245
(16.6)
(6.2)
8.63
(219.1)
4.31
(109.5)
0.245
(6.2)
BE1-11g
5.69 (144.5)
Outer Edge of Cover
Cut-Out
6.06 (154.0)
0.25 (6.35) diameter, 4 places
Figure 191. J Type Case - Cutout and Drilling Dimensions
2.84 (72.1)
C
L
3.03 (77.0)
263
0.655
(16.6)
8.25
(209.6)
4.13
(104.8)
P0072-13
Mounting
