Basler BE1-11g Instruction Manual page 218

206
Target
21-#-AB
21-#-BC
21-#-CA
24
27P-#-A/B/C
27X-#-3V0
27X-#-V1
27X-#-V2
27X-#-AUX
27X-#-3RD
32-#-A/B/C/T-Over
32-#-A/B/C/T-Under
40Q
40Z Z1/Z2
40Z Z1/Z2 VC
49RTD-# RTD-#-#
50-#-A/B/C
50-#-Residual
50-#-IND GND
50-#-Pos SEQ
50-#-Neg SEQ
50-#-Unbalance
50-#-67-A/B/C
50-#-67-Residual
50-#-67-IND GND
50-#-67-Neg SEQ
50BF
51-#-A/B/C
51-#-Residual
51-#-IND GND
51-#-Pos SEQ
51-#-Neg SEQ
51-#-Unbalance
51-#-67-A/B/C
51-#-67-Residual
51-#-67-IND GND
51-#-67-Neg SEQ
59-#-A/B/C
59X-#-3V0
Fault Reporting
Table 79. Targets as Displayed
Distance, AB
Distance, BC
Distance, CA
Overexcitation
Phase Undervoltage, A, B, or C
Auxiliary Undervoltage, 3V0-3ph VT
Auxiliary Undervoltage, Positive-Sequence
Auxiliary Undervoltage, Negative-Sequence
Auxiliary Undervoltage, Fundamental VX
Auxiliary Undervoltage, 3
Power, Phase A, B, C, or Total, Overpower
Power, Phase A, B, C, or Total, Underpower
Loss of Excitation, Reverse var Based
Loss of Excitation, Impedance Based, Zone 1 or 2
Loss of Excitation, Impedance Based, Zone 1 or 2, Voltage Control
Over/Undertemperature
Instantaneous Overcurrent, Phase A, B, or C
Instantaneous Overcurrent, Residual
Instantaneous Overcurrent, Independent Ground
Instantaneous Overcurrent, Positive-Sequence
Instantaneous Overcurrent, Negative-Sequence
Instantaneous Overcurrent, Unbalance
Directional Instantaneous Overcurrent, Phase A, B, or C
Directional Instantaneous Overcurrent, Residual
Directional Instantaneous Overcurrent, Independent Ground
Directional Instantaneous Overcurrent, Negative-Sequence
Breaker Failure
Inverse Overcurrent, Phase A, B, or C
Inverse Overcurrent, Residual
Inverse Overcurrent, Independent Ground
Inverse Overcurrent, Positive-Sequence
Inverse Overcurrent, Negative-Sequence
Inverse Overcurrent, Unbalance
Directional Inverse Overcurrent, Phase A, B, or C
Directional Inverse Overcurrent, Residual
Directional Inverse Overcurrent, Independent Ground
Directional Inverse Overcurrent, Negative-Sequence
Phase Overvoltage, A, B, or C
Auxiliary Overvoltage, 3V0-3ph VT
Description
rd
Harmonic VX
9424200994 Rev U
BE1-11g
