Basler BE1-11g Instruction Manual page 597

9424200994 Rev U
Analog to Digital Converter
Type .......................................................................... 16-bit
Sampling Rate ........................................................... 32 samples per cycle, adjusted to input frequency
Power Supply
Terminals................................................................... A6, A7
Option 1 (48/125 Vac/dc)
DC Operating Range ................................................. 35 to 150 Vdc
AC Operating Range ................................................. 55 to 135 Vac
Option 2 (125/250 Vac/dc)
DC Operating Range ................................................. 90 to 300 Vdc
AC Operating Range ................................................. 90 to 270 Vac
Option 3 (24 Vdc)
Operating Range ....................................................... 17 to 32 Vdc (down to 8 Vdc momentarily)
Frequency Range
Options 1 and 2 only ................................................. 40 to 70 Hz
Burden (Options 1, 2, and 3)
H and P Type Case ................................................... 10 W continuous, 12 W maximum with all outputs
J Type Case .............................................................. 12 W continuous, 14 W maximum with all outputs
Output Contacts
Make and Carry for Tripping Duty ............................. 30 A, 250 Vdc for 0.2 seconds per IEEE Std C37.90-
Break Resistive or Inductive...................................... 0.3 A at 125 or 250 Vdc (L/R = 0.04 maximum)
Terminals
OUT 1 ........................................................................ C1, C2
OUT 2 ........................................................................ C3, C4
OUT 3 ........................................................................ C5, C6
OUT 4 ........................................................................ C7, C8
OUT 5 ........................................................................ C9, C10
OUT 6 (Optional) ....................................................... E11, E12
OUT 7 (Optional) ....................................................... E9, E10
OUT 8 (Optional) ....................................................... E7, E8
OUT A ....................................................................... C11, C12
Contact-Sensing Inputs
Maximum Input Voltage
The maximum input voltages are the highest voltage for each power-supply range listed under the Power
Supply section.
Turn-On Voltage
Contact-sensing turn-on voltages are listed in Table 254.
BE1-11g
(10 to 125 Hz)
energized
energized
2005 - IEEE Standard for Relays and Relay
Systems Associated with Electric Power
Apparatus; 7 A continuous AC or DC
585
Specifications
