Basler BE1-11g Instruction Manual page 494

482
Pickup Verification (IG Mode)
Pickup Setting Range = 0.5 to 16 A for 5A sensing
Pickup Accuracy =
Dropout should occur between 93-99% of the actual pickup value.
Step Pickup Setting
6 0.5 A (5A sensing)
7 5.0 A (5A sensing)
7 16.0 A (5A sensing)
6 0.1 A (1A sensing)
7 1.0 A (1A sensing)
7 3.2 A (1A sensing)
6 0.1 A (SEF sensing)
7 0.5 A (SEF sensing)
7 0.8 A (SEF sensing)
* Dropout range is calculated from the pickup setting and may need adjusted based on actual pickup.
Timing Verification (IG Mode, 5A Sensing)
Time Dial Range = 0.0 to 9.9
Timing Accuracy = ±5% or ±1½ cycles, whichever is greater
Step Time Dial Time Curve
4 0.5
4 0.5
4 0.5
4 5.0
4 5.0
4 5.0
4 9.9
4 9.9
4 9.9
Timing Verification (IG Mode, 1A Sensing)
Time Dial Range = 0.0 to 9.9
Timing Accuracy = ±5% or ±1½ cycles, whichever is greater
Step Time Dial Time Curve
4 0.5
4 0.5
4 0.5
4 5.0
Inverse Overcurrent (51) Test
0.1 to 3.2 A for 1A sensing
0.01 to 0.8 A for SEF
±2% or ±50 mA, whichever is greater for 5A sensing
±2% or ±10 mA, whichever is greater for 1A sensing
±2.5% or ±2.5 mA, whichever is greater for SEF
Actual
Low
Pickup
0.45 A
4.90 A
15.68 A
0.09 A
0.98 A
3.13 A
0.0075 A
0.317 A
0.63 A
Applied Current
I2 1.00 A
I2 2.50 A
I2 12.50 A
I2 1.00 A
I2 2.50 A
I2 12.50 A
I2 1.00 A
I2 2.50 A
I2 12.50 A
Applied Current
I2 0.20 A
I2 0.50 A
I2 2.50 A
I2 0.20 A
Actual
High
Low*
Dropout
0.55 A 0.465 A
5.10 A 4.65 A
16.32 A 14.88 A
0.11 A 0.09 A
1.02 A 0.93 A
3.26 A 2.97 A
0.0125 A 0.0093 A
0.682 A 0.465 A
0.97 A 0.074 A
Low Actual Timing
0.444 sec
0.190 sec
0.100 sec
4.204 sec
1.798 sec
0.944 sec
8.300 sec
3.535 sec
1.844 sec
Low Actual Timing
0.444 sec
0.190 sec
0.100 sec
4.204 sec
9424200994 Rev U
Pass/Fail
High*
0.495 A P / F
4.95 A P / F
15.84 A P / F
0.09 A P / F
0.99 A P / F
3.16 A P / F
0.0099 A P / F
0.495 A P / F
0.792 A P / F
High Pass/Fail
0.491 sec P / F
0.240 sec P / F
0.150 sec P / F
4.647 sec P / F
1.988 sec P / F
1.044 sec P / F
9.173 sec P / F
3.907 sec P / F
2.038 sec P / F
High Pass/Fail
0.491 sec P / F
0.240 sec P / F
0.150 sec P / F
4.647 sec P / F
BE1-11g
