Remote Rtd Metering - Basler BE1-11g Instruction Manual

9424200994 Rev U
Setting
Disabled, Over, Under,
Mode
Source RTD Group 1 to RTD Group 7
Over Pickup
or 0 to 250 degrees C
Under Pickup
or 0 to 250 degrees C
Time Delay
Voting

Remote RTD Metering

RTD metering values are obtained through BESTCOMSPlus by using the Metering Explorer to open the
Analog Metering, RTD Meter tree branch. BESTCOMSPlus must be online with the BE1-11g to view RTD
metering. Alternately, values can be obtained through the front-panel display by navigating to the
Metering, Analog Metering, RTD Meter Input screen.
BE1-11g
Figure 98. Resistance Temperature Detector Settings Screen
Table 59. Operational Settings
Range
or Over & Under
32 to 482 degrees F
32 to 482 degrees F
0 to 600,000
1 to 24
Increment Unit of Measure
n/a
n/a
Calculated (F)
degrees
1 (C)
Calculated (F)
degrees
1 (C)
varies milliseconds
1
Resistance Temperature Detector (49RTD) Protection
Default
n/a Disabled
n/a RTD Group 1
32
32
0
units 1
157
