112
Setting
Direction
Directional Source*
Reset Timing
A Coefficient
B Coefficient
C Coefficient
N Coefficient
K Coefficient
R Coefficient
Voltage Restraint
Mode
Voltage Restraint
Setpoint
* For protection systems equipped with two sets of CTs.
Inverse Overcurrent (51) Protection
Range
Forward, Reverse, or Non-
Directional
67-1 or 67-2
Integrating or Instantaneous
0 to 600
0 to 25
0 to 1
0.5 to 2.5
n/a
0 to 30
Disabled, Control, or Restraint
0 or 30 to 250 secondary
Unit of
Increment
Measure
n/a n/a
n/a n/a
n/a n/a
0.00001 A Coefficient
0.00001 B Coefficient
0.00001 C Coefficient
0.00001 N Coefficient
n/a K Coefficient
0.00001 R Coefficient
n/a n/a
varies volts
9424200994 Rev U
Default
Non-
Directional
67-1
Instantaneous
0.26630
0.03393
1.00000
1.29690
0.02800
0.50000
Disabled
0
