Basler BE1-11g Instruction Manual page 452

440
† VA Low and High values are calculated as VA=3V0+150 V nominal.
Timing Verification (3V0 Mode)
Time Delay Range = 50 to 600,000 ms
Timing Accuracy = ±0.5% or ±2 cycles, whichever is greater
Step Time Delay Setting
4 2,000 ms
5 5,000 ms
5 10,000 ms
Pickup Verification (V1 Mode)
Pickup Setting Range = 1 to 150 V
Pickup Accuracy = ±2% or ±1 V, whichever is greater
Dropout/Pickup Ratio = 98% ±1%
Pickup
Setting
Step
V1 VA V1
6 82.0 246.0 80.3
7 42.0 126.0 41.0
7 25.0 75.0 24.0
* Dropout range is calculated from the pickup setting and may need adjusted based on actual pickup.
Timing Verification (V1 Mode)
Time Delay Range = 50 to 600,000 ms
Timing Accuracy = ±0.5% or ±2 cycles, whichever is greater
Step Time Delay Setting
4 2,000 ms
5 5,000 ms
5 10,000 ms
Pickup Verification (V2 Mode)
Pickup Setting Range = 1 to 150 V
Pickup Accuracy = ±2% or ±1 V, whichever is greater
Dropout/Pickup Ratio = 98% ±1%
Pickup
Setting
Step
V1 VA V1
6 82.0 246.0 80.3
7 42.0 126.0 41.0
7 25.0 75.0 24.0
* Dropout range is calculated from the pickup setting and may need adjusted based on actual pickup.
Timing Verification (V2 Mode)
Time Delay Range = 50 to 600,000 ms
Auxiliary Overvoltage (59X) Test
Low
1,968 ms
4,968 ms
9,950 ms
Low High
Actual
Pickup
VA V1
240.9 83.6
123.0 43.0
72.0 26.0
Low
1,968 ms
4,968 ms
9,950 ms
Low High
Actual
Pickup
VA V1
240.9 83.6
123.0 43.0
72.0 26.0
Actual Timing
Low*
Actual
Dropout
VA V1 VA
250.8 82.8 248.4
129.0 42.4 127.2
78.0 25.2 75.6
Actual Timing
Low*
Actual
Dropout
VA V1 VA
250.8 82.8 248.4
129.0 42.4 127.2
78.0 25.2 75.6
9424200994 Rev U
High Pass/Fail
2,032 ms P / F
5,032 ms P / F
10,050 ms P / F
High*
Pass/Fail
V1 VA
84.4 253.2 P / F
43.2 129.6 P / F
25.7 77.1 P / F
High Pass/Fail
2,032 ms P / F
5,032 ms P / F
10,050 ms P / F
High*
Pass/Fail
V1 VA
84.4 253.2 P / F
43.2 129.6 P / F
25.7 77.1 P / F
BE1-11g
