Basler BE1-11g Instruction Manual page 525

9424200994 Rev U
Step Pickup Setting
3 500 W
5 1,000 W
5 2,000 W
* Dropout range is calculated from the pickup setting and may need adjusted based on actual pickup.
Reverse Tripping Direction (Overpower)
Pickup Setting Range = 1 to 6,000 Watts for 5A sensing
Pickup Accuracy = ±3 or ±2 W, whichever is greater
Dropout should occur between 95-99% of the actual pickup value.
Step Pickup Setting
3 500 W
* Dropout range is calculated from the pickup setting and may need adjusted based on actual pickup.
Forward Tripping Direction (Underpower)
Pickup Setting Range = 1 to 6,000 Watts for 5A sensing
Pickup Accuracy = ±3 or ±2 W, whichever is greater
Reset should occur between 95-99% of the actual pickup value.
Step Setting
3 500 W 485.0 W
5 250 W 242.5 W
5 50 W 48.5 W
* Reset range is calculated from the pickup setting and may need adjusted based on actual pickup.
Reverse Tripping Direction (Underpower)
Pickup Setting Range = 1 to 6,000 Watts for 5A sensing
Pickup Accuracy = ±3 or ±2 W, whichever is greater
Reset should occur between 95-99% of the actual pickup value.
Step Pickup Setting
3 500 W
* Reset range is calculated from the pickup setting and may need adjusted based on actual pickup.
BE1-11g
Low Actual Pickup
485 W
970 W
1940 W
1 to 1,200 Watts for 1A sensing
Low Actual Pickup
485 W
1 to 1,200 Watts for 1A sensing
Low Pickup High
515.0 W
257.5 W
51.5 W
1 to 1,200 Watts for 1A sensing
Low Actual Pickup
485 W
High Low* Actual Dropout
515 W 475 W
1,030 W 950 W
2,060 W 1900 W
High Low* Actual Dropout
515 W 475 W
Low* Dropout
475.0 W
237.5 W
47.5 W
High Low* Actual Dropout
515 W 475 W
513
Pass/Fail
High*
495 W P / F
990 W P / F
1,980 W P / F
Pass/Fail
High*
495 W P / F
Pass/Fail
High*
495.0 W P / F
247.5 W P / F
49.5 W P / F
Pass/Fail
High*
495 W P / F
Power (32) Test
