Basler BE1-11g Instruction Manual page 506

494
Setting
Phase VT Ratio 1
Phase VT 4W-Y
Connection
27/59 Mode PN
Circuit 1 WYE
Transformer
Connection
Circuit 1 Ground No
Compensation
(Optional) Circuit Primary
1 Diff. Circuit
Circuit 1 Polarity Normal
Circuit 1 Phase A
Relationship
Circuit 2 WYE
Transformer
Connection
Circuit 2 Ground No
Compensation
(Optional) Circuit Secondary
2 Diff. Circuit
Circuit 2 Polarity Normal
Circuit 2 Phase A
Relationship
(Optional) IEC Wye
Setup Winding 1 Primary
(Optional) IEC y0
Setup Winding 2 Secondary
Circuit 1 Tap 2.00
Circuit 2 Tap 2.00
Mode Percent
Differential
Phase Current Differential (87) Test
Value BESTCOMSPlus Screen
System Parameters, Sensing
Transformers
System Parameters, Sensing
Transformers
System Parameters, Sensing
Transformers
System Parameters, Transformer
Setup
System Parameters, Transformer
Setup
System Parameters, Transformer
Setup
System Parameters, Transformer
Setup
System Parameters, Transformer
Setup
System Parameters, Transformer
Setup
System Parameters, Transformer
Setup
System Parameters, Transformer
Setup
System Parameters, Transformer
Setup
System Parameters, Transformer
Setup
System Parameters, Transformer
Setup, IEC Transformer Setup
System Parameters, Transformer
Setup, IEC Transformer Setup
System Parameters, Transformer
Setup
System Parameters, Transformer
Setup
Protection, Current, Phase
Differential (87)
9424200994 Rev U
Description
Sets phase VT ratio to 1
Sets phase VT connection
to 4W-Y
Sets 27/59 mode to phase-
neutral
Configures the primary side
for a WYE connection
Disables the primary
winding zero sequence trap
Establishes circuit 1 on the
primary side of the
transformer. For report
labeling purposes only.
Sets the phase rotation of
circuit 1 for ABC
Sets A-phase in circuit 1
equal to the phase
relationship setting for
circuit 2
Configures the secondary
side for a WYE connection
Disables the secondary
winding zero sequence trap
Establishes circuit 2 on the
secondary side of the
transformer. For report
labeling purposes only.
Sets the phase rotation of
circuit 2 for ABC
Sets A-phase in circuit 2
equal to the phase
relationship setting for
circuit 1
Configures the primary side
for a WYE connection
Configures the secondary
side for a WYE connection
with normal ABC phase
rotation
Sets the tap for circuit 1 to
2.00 A secondary
Sets the tap for circuit 2 to
2.00 A secondary
Sets the type of operation
protection to traditional
phase current differential
BE1-11g
