Logic Timers (62)
Eight logic timers with six modes of operation emulate virtually any type of timer.
Lockout Functions (86)
Two lockout elements are provided.
BESTlogic™Plus Programmable Logic
Each BE1-11g protection and control function is implemented in an independent function element. Every
function block is equivalent to its single function, discrete device counterpart so it is immediately familiar
to the protection engineer. Each independent function block has all of the inputs and outputs that the
discrete component counterpart may have. Programming with BESTlogicPlus is equivalent to choosing
the devices required by your protection and control scheme and then drawing schematic diagrams to
connect the inputs and outputs to obtain the desired operating logic.
Custom logic settings allow you to tailor the BE1-11g functionality to match the needs of your operation's
practices and power system requirements.
Metering Functions
Metering is provided for the following parameters:
•
Primary and secondary voltages (P-P, P-N, V1, V2, 3V0, Vx, Vx 3
•
Frequency (phase and auxiliary)
•
Primary and secondary currents (phase, ground, I1, I2, 3I0)
•
Power (real, reactive, apparent)
•
Power factor
•
Synchronization
•
Phase differential (Iop, Ir, 2
•
Neutral differential (Iop)
•
Energy (total watthours and total varhours)
•
Analog inputs and outputs
•
RTD input temperatures

Model and Style Number Description

BE1-11g electrical characteristics and operational features are defined by a combination of letters and
numbers that make up the style number. The style number describes the options included in a specific
device and appears on labels located on the front panel and inside the case. Upon receipt of a BE1-11g,
be sure to check the style number against the requisition and the packing list to ensure that they agree.
The model number and style number are shown in Figure 1.
