Basler BE1-11g Instruction Manual page 655

9424200994 Rev U
0 – 10 Vdc
Transducer
Transducer
External RTD Input Connections
External 2-wire RTD input connections are shown in Figure 390. Figure 391 shows external 3-wire RTD
input connections.
BE1-11g
Voltage
Figure 388. Analog Inputs - Voltage Input Connections
4 – 20 mA
Current
Figure 389. Analog Inputs - Current Input Connections
RED
BLACK
Jumper
Figure 390. External Two-Wire RTD Input Connections
RTD Module
AIN I+
–
AIN
AIN V+
RTD Module
AIN I+
–
AIN
AIN V+
RTD Module
RTD1+
RTD1–
RTD1C
643
RTD Module
