Basler BE1-11g Instruction Manual page 73

9424200994 Rev U
Setting
Mode
Pickup
Inhibit Level
Timing Mode
Time Delay (Definite
Timing)
Time Dial (Inverse
Timing)
Curve
Reset Timing
A Constant
B Constant
C Constant
N Constant
R Constant
BE1-11g
Figure 46. Phase Undervoltage Settings Screen
Table 16. Operational Settings
Range
Disabled,
One of Three,
Two of Three,
or Three of Three
0 or 1 to 300 secondary
0 or 1 to 300 secondary
Definite or Inverse
50 to 600,000
0 to 9.9
P, T1, T2, T3, or T4
Integrating or
Instantaneous
0 to 600
0 to 25
1 to 3
0.5 to 2.5
0 to 30
Unit of
Increment
Measure
n/a n/a
0.1 volts
0.1 volts
n/a n/a
varies milliseconds
0.1 units
n/a n/a
n/a n/a
0.00001 A Constant
0.00001 B Constant
0.00001 C Constant
0.00001 N Constant
0.00001 R Constant
Phase Undervoltage (27P) Protection
61
Default
Disabled
0
0
Definite
50
0
P
Instantaneous
1.00000
0.00000
1.00000
1.00000
0.00000
