136
Block Logic Input
The Block input provides logic-supervision control of the element. When true, the Block input disables the
element by forcing the Trip and Pickup outputs to logic 0 and resetting the element timer. Connect the
element Block input to the desired logic in BESTlogicPlus. When the element is initially selected from the
Elements view, the default condition of the Block input is a logic 0.

Logic Connections

Power element logic connections are made on the BESTlogicPlus screen in BESTCOMSPlus. The power
element logic block is illustrated in Figure 84. Logic inputs and outputs are summarized in Table 48.
Name Logic Function
Block
Trip
Pickup

Operational Settings

Power element operational settings are configured on the Power (32) settings screen (Figure 85) in
BESTCOMSPlus. Setting ranges and defaults are summarized in Table 49.
Setting
Disabled, One of Three, Two of Three, Three
Mode
0 or 1 to 6,000 (5A CTs) secondary
Pickup
0 or 1 to 1,200 (1A CTs) secondary
Time
Delay
Power (32) Protection
Figure 84. Power Element Logic Block
Table 48. Logic Inputs and Outputs
Input Disables the 32 function when true
Output True when the 32 element is in a trip condition
Output True when the 32 element is in a pickup condition
Figure 85. Power Settings Screen
Table 49. Operational Settings
Range
of Three, or Total Power
0 or 50 to 600,000
9424200994 Rev U
Purpose
Unit of
Increment
Measure
n/a n/a
varies watts
varies milliseconds
Default
Disabled
0
0
BE1-11g
