Functional Test Reports

Restrained Pickup Verification (Maximum Restraint)
Pickup Accuracy = ±2% or ±0.05A, whichever is greater.
Dropout = (1 - 0.1) * pickup
Pickup
Step
Setting
5/6 - MRPU 0.70 A
8/9 - MRPU 0.30 A
11 – Slope 1 3.75 A
13 – Slope 1 2.40 A
15 – Slope 2 8.83 A
17 – Slope 2 5.10 A
* Dropout verified in previous steps.
Restrained Pickup Verification (Average Restraint)
Pickup Accuracy = ±2% or ±0.05A, whichever is greater.
Dropout = (1 - 0.1) * pickup
Pickup
Step
Setting
5/6 - MRPU 0.70 A
8/9 - MRPU 0.30 A
11 – Slope 1 3.67 A
13 – Slope 1 2.46 A
15 – Slope 2 8.25 A
17 – Slope 2 5.32 A
* Dropout verified in previous steps.
Restrained Timing Verification (Maximum or Average Restraint)
Time Delay Range = 0 to 60,000 ms
Timing Accuracy = ±0.5% or ±1/2 cycle, whichever is greater, plus 1¼ cycles maximum for currents ≥ 5
times the pickup setting. 1¾ cycles maximum for a current of 2 times pickup. Two cycles maximum for a
current of 1.05 times the pickup setting.
Step Time Delay Setting
4 100 ms
Unrestrained Pickup Verification
Pickup Accuracy = ±2% or ±0.05A, whichever is greater.
Step Pickup Setting
4 4.00 A
Phase Current Differential (87) Test
Actual
Low
Pickup
0.65 A 0.75 A
0.25 A 0.35 A
3.68 A 3.83 A
2.35 A 2.45 A
8.66 A 9.00 A
5.00 A 5.20 A
Actual
Low
Pickup
0.65 A 0.75 A
0.25 A 0.35 A
3.59 A 3.74 A
2.41 A 2.51 A
8.09 A 8.42 A
5.21 A 5.42 A
Low
62.5 ms
Low
3.92 A
Actual
High Low
Dropout
0.59 A
0.28 A
N/A* N/A*
N/A* N/A*
N/A* N/A*
N/A* N/A*
Actual
High Low
Dropout
0.59 A
0.28 A
N/A* N/A*
N/A* N/A*
N/A* N/A*
N/A* N/A*
Actual Timing
Actual Pickup
4.08 A
9424200994 Rev U
High Pass/Fail
0.68 A P / F
0.39 A P / F
N/A*
P / F
N/A* P / F
N/A* P / F
N/A*
P / F
High Pass/Fail
0.68 A P / F
0.39 A P / F
N/A* P / F
N/A* P / F
N/A* P / F
N/A* P / F
High Pass/Fail
163 ms P / F
High Pass/Fail
P / F
