Power; Retrieving Demand Reporting Information - Basler BE1-11g Instruction Manual

234
Table 89 summarizes the demand current reporting settings.
Setting
Phase Interval
Neutral/Ground Interval
Negative-Sequence Interval
Phase Current Threshold
Neutral/Ground Current Threshold
Negative-Sequence Current
Threshold

Power

Demand values are continuously calculated for real power (A kW, B kW, C kW, Total kW), reactive power
(A var, B var, C var, Total var), and apparent power (A VA, B VA, C VA, Total VA).
Demand Power Reporting Settings
BESTCOMSPlus Navigation Path: Settings Explorer, Alarm Configuration, Demands
HMI Navigation Path: Settings Explorer, Alarm Configuration, Demands
Settings are made using BESTCOMSPlus. Use the Settings Explorer to open the Alarm Configuration,
Demands tree branch. Demand settings for real power thresholds include Forward Watt and Reverse
Watt. Demand settings for reactive power include Forward Var and Reverse Var. A setting for apparent
power threshold is also provided. The demand power interval is defined by the Phase Interval setting.
Enter the appropriate demand power reporting settings. Refer to Figure 162.
Table 90 summarizes the demand power reporting settings.
Setting
Forward Watt Threshold
Reverse Watt Threshold
Forward var Threshold
Reverse var Threshold
VA Threshold

Retrieving Demand Reporting Information

BESTCOMSPlus Navigation Path: Metering Explorer, Demand
HMI Navigation Path: Metering Explorer, Demand Meter
Values and timestamps in the demand registers are reported in primary values. They can be read at the
front-panel display, through BESTCOMSPlus, and through the web page interface.
Peak demand values can be preset by pressing the Edit key and changing the value. Write access to the
Reports functional area is required to preset values at the front panel.
To access demand data through BESTCOMSPlus, use the Metering Explorer to open the Demand tree
branch and select Demand Current (Figure 163), Demand Power (Figure 164), Demand Reactive Power,
Demands
Table 89. Demand Current Reporting Settings
Range
0 or 1 to 60
0 or 1 to 60
0 or 1 to 60
0 or 0.5 to 16
secondary
0 or 0.5 to 16
secondary
0 or 0.5 to 16
secondary
Table 90. Demand Power Reporting Settings
Range
0 or 1 to 8,500 secondary
0 or 1 to 8,500 secondary
0 or 1 to 8,500 secondary
0 or 1 to 8,500 secondary
0 or 1 to 8,500 secondary
Unit of
Increment
Measure
0.5 minutes
0.5 minutes
0.5 minutes
0.01 amps
0.01 amps
0.01 amps
Increment Unit of Measure
varies watts
varies watts
varies vars
varies vars
varies VA
9424200994 Rev U
Default
15
15
15
0
0
0
Default
0
0
0
0
0
BE1-11g
