46
Name Function
Block
Trip
Pickup

Operational Settings

Overexcitation operational settings are configured on the Overexcitation (24) settings screen (Figure 37)
in BESTCOMSPlus. Setting ranges and defaults are summarized in Table 10.
Setting
Mode
Pickup (Inverse Time)
Time Dial (Inverse Time)
Reset Dial (Inverse Time)
Curve Exponent (Inverse Time)
Pickup (Definite Time 1 & 2)
Time Delay (Definite Time 1 & 2)
Overexcitation (24) Protection
Table 9. Logic Inputs and Outputs
Input Disables the 24 function when true
Output True when the 24 element is in trip condition
Output True when the 24 element is in pickup condition
Figure 37. Overexcitation Settings Screen
Table 10. Operational Settings
Range
Disabled or Enabled
0 or 0.5 to 6 secondary
0 to 9.9
0 to 9.9
0.5, 1, or 2
0 or 0.5 to 6 secondary
50 to 600,000
Purpose
Increment Unit of Measure
n/a n/a
0.01 v/Hz
0.1 units
0.1 units
n/a n/a
0.01 v/Hz
varies milliseconds
9424200994 Rev U
Default
Disabled
0
0
0
1
0
50
BE1-11g
