Basler BE1-11g Instruction Manual page 327

9424200994 Rev U
Name
Physical Outputs
OUT1 – OUT8 and
OUTA
Off-Page Output
Off-Page Input
Logic Alarm
Major Alarm
Minor Alarm
Relay Trouble Alarm
Targets
Components
This group contains Logic Gates, Pickup and Dropout Timers, Latches, Logic Counters, and Comment
Blocks. Double-click or right-click on a gate to change the type. Table 104 lists the names and
descriptions of the objects in the Components group.
Name
AND
NAND
BE1-11g
Description
Output Objects
Physical Outputs 1 through 8 and A.
Off-Page Objects
Used in conjunction with the Off-Page Input to transform
an output on one logic page into an input on another logic
page. Outputs can be renamed by right-clicking and
selecting Rename Output. Right-clicking will also show
pages that the corresponding inputs can be found on.
Selecting the page will take you to that page.
Used in conjunction with the Off-Page Output to transform
an output on one logic page into an input on another logic
page. Inputs can be renamed by right-clicking and
selecting Rename Input. Right-clicking will also show
pages that the corresponding outputs can be found on.
Selecting the page will take you to that page.
True when the Logic Alarm is true. Refer to the Alarms
chapter for more information.
True when the Major Alarm is true. Refer to the Alarms
chapter for more information.
True when the Minor Alarm is true. Refer to the Alarms
chapter for more information.
True when a Relay Trouble alarm is active. Refer to the
Alarms chapter for more information.
True when targets are active. Refer to the Fault Reporting
chapter for more information.
Table 104. Components Group, Names and Descriptions
Description
Logic Gates
Input Output
0 0
0 1
1 0
1 1
Input Output
0 0
0 1
1 0
1 1
Alarms
0
0
0
1
1
1
1
0
315
Symbol
Symbol
BESTlogic™Plus
