Physical Port Selection (Ethernet or RS-485) is available only for
Ethernet Protocol options 3 and 4 and only when RS-485 port protocol
option is N (None). RTD module communication over RS-485 is not
available when the physical port for DNP communication is RS-485.
Unsolicited Response Support
The Unsolicited Response Support screen (Figure 257) configures BE1-11g unsolicited responses over a
DNP network and selects the classes of events that trigger the responses.
Figure 257. DNP Settings, Unsolicited Response Support Screen
Default Variations
The Default Variations screen (Figure 258) is used to configure the binary and analog inputs and analog
output status.
Communication
Figure 256. DNP Settings, Miscellaneous Settings Screen
Note
