Basler BE1-11g Instruction Manual page 703

9424200994 Rev U
Manual
Revision and Date
E, Mar-11
F, Sep-12
G, Nov-12
H, Jan-13
I
J, Mar-13
K, Dec-13
L, Feb-14
M, Apr-14
BE1-11g
•
Replaced Figure 3-13, Auto Export Metering (Added Filter button
on screen)
•
Replaced Figure 13-18, Voltage Sensing, Alternate VTP Inputs
(Added connection between C14 & C16 in image B)
•
Converted manual into new style and structure
•
Added support for BE1-11m firmware version 2.06.00 and
BESTCOMSPlus version 3.00.02
•
Added description of Delta/Wye Compensation Enable setting
and replaced Figure 84, Distance Settings Screen in the
Distance Protection (21) chapter
•
Added Storage statement in the Quick Start chapter
•
Minor text edits throughout manual
•
Improved the 87N element equations and test procedure
•
Improved the 40Z element test procedure
•
Added case overlap in Figure 183, J Type Case - Cutout and
Drilling Dimensions in the Mounting chapter
•
Added optional second set of CTs in Figure 204
•
Added drawings in the Power System Applications chapter
•
Added Storage statement in the RTD Module chapter
•
This revision letter not used
•
Added 10-Second Frequency description in the Power Quality
chapter
•
Added Figure 206, Single-Phase Current Sensing Connections
in the Typical Connections chapter
•
Added Specifications - 25 Hz Operation chapter
•
Added Digital Points chapter
•
Added support for BE1-11g firmware version 2.07.00 and
BESTCOMSPlus version 3.05.02
•
Moved revision history to the back of the manual
•
Added description of QR code in Tables 2 and 3
•
Added QR code in Figures 2, 23, and 24
•
Updated PC requirements for BESTCOMSPlus software
•
Moved Frequently Asked Questions from the Troubleshooting
chapter into a new chapter
•
Added Table 11, Common System and Sensing Transformer
Combinations for the 25 element
•
Corrected trip circuit monitor jumper illustration
•
Removed product registration information
•
Added support for BE1-11g firmware version 2.08.00 and
BESTCOMSPlus version 3.06.00
•
Added a Stator Ground (64G) Protection chapter
•
Added Step 2 and updated Step 3 under Element Operation,
Control of Virtual Control Switches in the Virtual Control
Switches (43) chapter
•
Added total height to the H1 Panel-Mount Case Dimensions
figure in the Mounting chapter
•
Added Offline Logic Simulator description in the BESTlogicPlus
chapter
•
Changed the order of the Inverse Overcurrent (51) curves in the
Time Curve Characteristics chapter
Change
691
Revision History
