Basler BE1-11g Instruction Manual page 116

104
Setting
Mode
Source*
Pickup (Phase &
Ground)
Control Timer
Delay Timer
* For protection systems equipped with two sets of CTs.
Breaker Failure (50BF) Protection
Table 36. Operational Settings
Range
Disabled or Enabled
CT Circuit1 or CT Circuit 2
0 or 0.25 to 10.00 (5A CTs)
secondary
0 or 0.05 to 2.00 (1A CTs)
secondary
0 or 0.01 to 0.5 (SEF)
secondary
0 or 50 to 999
0 or 50 to 999
Unit of
Increment
Measure
n/a n/a
n/a n/a
varies amps
varies milliseconds
varies milliseconds
9424200994 Rev U
Default
Disabled
CT Circuit
1
0
50
50
BE1-11g
