Basler BE1-11g Instruction Manual page 475

9424200994 Rev U
Pickup Verification (3I0 Mode)
Pickup Setting Range = 0.5 to 150 A for 5A sensing
Pickup Accuracy =
Dropout should occur between 93-99% of the actual pickup value.
Step Pickup Setting
6 0.5 A (5A CT)
7 5.0 A (5A CT)
7 20.0 A (5A CT)
6 0.1 A (1A CT)
7 1.0 A (1A CT)
7 4.0 A (1A CT)
* Dropout range is calculated from the pickup setting and may need adjusted based on actual pickup.
Timing Verification (3I0 Mode)
Time Delay Range = 0 to 60,000 ms
Timing Accuracy = ±1% or ±½ cycle, whichever is greater + 3 cycles max for currents 1.5 x pickup
Step Time Delay Setting
4 2,000 ms
5 5,000 ms
5 10,000 ms
Pickup Verification (I2 Mode)
Pickup Setting Range = 0.5 to 150 A for 5A sensing
Pickup Accuracy =
Dropout should occur between 93-99% of the actual pickup value.
Pickup Setting
Step I2 IA
0.5
6 1.5
(5A CT)
5.0
7 15.0
(5A CT)
9.0
7 27.0
(5A CT)
0.1
6 0.3
(1A CT)
1.0
7 3.0
(1A CT)
1.8
7 5.4
(1A CT)
* Dropout range is calculated from the pickup setting and may need adjusted based on actual pickup.
BE1-11g
0.1 to 30 A for 1A sensing
±3% or ±75 mA, whichever is greater for 5A sensing
±3% or ±15 mA, whichever is greater for 1A sensing
Low Actual Pickup
0.425 A
4.85 A
19.4 A
0.085 A
0.97 A
3.88 A
Low
1,942 ms
4,927 ms
9,902 ms
0.1 to 30 A for 1A sensing
±3% or ±75 mA, whichever is greater for 5A sensing
±3% or ±15 mA, whichever is greater for 1A sensing
Low
Actual
I2 IA Pickup I2
0.42 1.26 0.57
4.85 14.55 5.15
8.73 26.19 9.27
0.08 0.24 0.11
0.97 2.91 1.03
1.74 5.22 1.85
High Actual Dropout
Low*
0.575 A 0.465 A
5.15 A 4.65 A
20.6 A 18.6 A
0.115 A 0.093 A
1.03 A 0.93 A
4.12 A 3.72 A
Actual Timing
Low*
High
IA I2 IA
1.71 0.46 1.38
15.45 4.65 13.95
27.81 8.37 25.11
0.33 0.093 0.279
3.09 0.93 2.79
5.55 1.67 5.01
Instantaneous Overcurrent (50) Test
Pass/Fail
High*
0.495 A
4.95 A
19.8 A
0.099 A
0.99 A
3.96 A
High Pass/Fail
2,058 ms P / F
5,073 ms P / F
10,098 ms P / F
High*
Actual
Dropout I2 IA
0.49 1.47
4.95 14.85
8.91 26.73
0.099 0.297
0.99 2.97
1.78 5.34
463
P / F
P / F
P / F
P / F
P / F
P / F
Pass/Fail
P / F
P / F
P / F
P / F
P / F
P / F
