Operational Settings - Basler BE1-11g Instruction Manual

9424200994 Rev U
Name
Automatic
D0, D1, D2, D3
SG0, SG1, SG2, SG3
SGCACTIVE
SGCLOVRD

Operational Settings

Setting group operational settings are configured on the Setting Group Setup screen (Figure 126) in
BESTCOMSPlus. Setting ranges and defaults are summarized in Table 75.
BE1-11g
Figure 125. Setting Group Logic Block
Table 74. Logic Inputs and Outputs
Logic
Function
True when automatic control is enabled and false when logic
Input
control is enabled
Inputs Meaning depends upon the Mode setting
Outputs True for the active setting group
Output True when Setting Group Control is Active
Output True when Setting Group Control is overridden by logic
Purpose
Setting Groups
191
