Setting Range
Disabled
Mode Discrete Inputs
Binary Inputs
CT Circuit 1 or CT
Source*
Circuit 2
0 to 25A (5A CTs)
Switch
0 to 5A (1A CTs)
Threshold
Switch 0 = Disabled
Time 1 to 60 minutes
0 to 25A (5A CTs)
Return 0 to 5A (1A CTs)
Threshold
0 = Disabled
Return
1 to 60 minutes
Time
Setting Groups
Figure 126. Setting Group Setup Screen
Table 75. Operational Settings
Sets the mode of the setting group selection function.
(If Auto mode is desired, logic mode must be either 1 or
2.)
n/a
Measured current of the SG0 Monitor Setting that must
be exceeded for a setting group change to occur. (Set in
increments of 0.01A, secondary amps.)
Time, in minutes, that determines when a setting change
occurs once the Switch Threshold setting is exceeded.
Measured current of the SG0 Monitor Setting that the
monitored current must decrease below in order for a
return to SG0. (Set in increments of 0.01A, secondary
amps.)
Time, in minutes, that determines when a return to SG0
will occur once the monitored current has decreased
below the Return Threshold setting.
