Parameter
RTD 2-1 through RTD 2-12
Remote Analog Output Metering
Analog output metering values are obtained through BESTCOMSPlus by using the Metering Explorer to
open the Analog Metering, Analog Outputs tree branch. BESTCOMSPlus must be online with the BE1-
11g to view analog output metering. Alternately, values can be obtained through the front-panel display by
navigating to Metering > Analog Metering > Analog Output.

Remote RTDs Configuration

The RTD module provides 12 RTD inputs. The BE1-11g supports two RTD modules at once. The RTDs
are always monitored and their status is displayed on the appropriate metering screens.
Protection settings for remote RTDs are described in the Resistance Temperature Detector (49RTD)
Protection chapter.
Out of Range Alarm
The BE1-11g reports an Out of Range alarm when the resistance from an RTD has exceeded an
expected range for a properly functioning RTD. Exceeding the range indicates that the RTD may be
shorted or open and cannot be relied on to provide thermal detection. Table 265 defines the resistance
and equivalent temperature levels that will result in an Out of Range alarm.
Table 265. Out of Range Alarm Resistance/Temperature Levels
RTD Type Min. Ohms
10 Ω Cu 7 Ω
100 Ω Pt 76 Ω
100 Ω Ni 69 Ω
120 Ω Ni 79 Ω
Configuration Settings
BESTCOMSPlus Navigation Path: Settings Explorer, Programmable Inputs, Remote RTD
HMI Navigation Path: Settings Explorer, RTD Types
Configuration settings are made using the BE1-11 plugin for BESTCOMSPlus. Before making
configuration settings, remote module communications must be configured on the System Parameters,
Remote Module Communications screen. To program the configuration settings, use the Settings
Explorer to open the Programmable Outputs, Remote RTD, RTD Type Selection tree branch and select
RTD Type Selection. Use the drop-down menu to select RTD Type. Refer to Figure 408.
BE1-11g
Unit
Degrees C or F
(depends on System
Units setting)
Min. Temperature
−61°C (−77.8°F)
−61°C (−77.8°F)
−61°C (−77.8°F)
−61°C (−77.8°F)
Note
Max. Ohms Max. Temperature
20 Ω
261°C (501.8°F)
198 Ω
261°C (501.8°F)
224 Ω
181°C (357.8°F)
383 Ω
261°C (501.8°F)
655
RTD Module
