Table C−5. Status Register Bits
Reg C2xLP Bit
Name
ST0 DP
INTM
OVM
OV
ARP
ST1 PM
XF
C
SXM
TC
CNF
ARB
C2xLP Reset Value
XXXXXXXXX
1
X
0
XXX
00 (no shift)
1
1
1
X
0
XXX
C2xLP and C28x Architectural Differences
C28x Bit Name
SXM
OVM
TC
C
Z
N
V
PM
INTM
DBGM
PAGE0
VMAP
SPA
LOOP
EALLOW
IDLESTAT
AMODE
OBJMODE
CNF not implement-
ed
M0M1MAP
XF
ARP
Register Reset Conditions
C28x Reset Value
0
0
0
0
0
0
0
000 (left shift 1)
1
1
0
1
0
0
0
0
0
0
0
1
0
000
