www.ti.com

1 TMS320C6454 Fixed-Point Digital Signal Processor

1.1 Features

High-Performance Fixed-Point DSP (C6454)
– 1.39-, 1.17-, and 1-ns Instruction Cycle Time
– 720-MHz, 850-MHz, and 1-GHz Clock Rate
– Eight 32-Bit Instructions/Cycle
– 8000 MIPS/MMACS (16-Bits)
– Commercial Temperature [0°C to 90°C]
TMS320C64x+™ DSP Core
– Dedicated SPLOOP Instruction
– Compact Instructions (16-Bit)
– Instruction Set Enhancements
– Exception Handling
TMS320C64x+ Megamodule L1/L2 Memory
Architecture:
– 256K-Bit (32K-Byte) L1P Program Cache
[Direct Mapped]
– 256K-Bit (32K-Byte) L1D Data Cache
[2-Way Set-Associative]
– 8M-Bit (1048K-Byte) L2 Unified Mapped
RAM/Cache [Flexible Allocation]
– 256K-Bit (32K-Byte) L2 ROM
– Time Stamp Counter
Endianess: Little Endian, Big Endian
64-Bit External Memory Interface (EMIFA)
– Glueless Interface to Asynchronous
Memories (SRAM, Flash, and EEPROM) and
Synchronous Memories (SBSRAM and ZBT
SRAM)
– Supports Interface to Standard Sync
Devices and Custom Logic (FPGA, CPLD,
ASICs, etc.)
– 32M-Byte Total Addressable External
Memory Space
Please be aware that an important notice concerning availability, standard warranty, and use in critical applications of Texas
Instruments semiconductor products and disclaimers thereto appears at the end of this document.
All trademarks are the property of their respective owners.
PRODUCT PREVIEW information concerns products in the
formative or design phase of development. Characteristic data and
other specifications are design goals. Texas Instruments reserves
the right to change or discontinue these products without notice.
Fixed-Point Digital Signal Processor
SPRS311A – APRIL 2006 – REVISED DECEMBER 2006
32-Bit DDR2 Memory Controller (DDR2-533
SDRAM)
EDMA3 Controller (64 Independent Channels)
32-/16-Bit Host-Port Interface (HPI)
32-Bit 33-/66-MHz, 3.3-V Peripheral Component
Interconnect (PCI) Master/Slave Interface
Conforms to PCI Specification 2.3
One Inter-Integrated Circuit (I
Two McBSPs
10/100/1000 Mb/s Ethernet MAC (EMAC)
– IEEE 802.3 Compliant
– Supports Multiple Media Independent
Interfaces (MII, GMII, RMII, and RGMII)
– 8 Independent Transmit (TX) and
8 Independent Receive (RX) Channels
Two 64-Bit General-Purpose Timers,
Configurable as Four 32-Bit Timers
16 General-Purpose I/O (GPIO) Pins
System PLL and PLL Controller
Secondary PLL and PLL Controller, Dedicated
to EMAC and DDR2 Memory Controller
IEEE-1149.1 (JTAG™)
Boundary-Scan-Compatible
697-Pin Ball Grid Array (BGA) Package
(ZTZ or GTZ Suffix), 0.8-mm Ball Pitch
0.09- m/7-Level Cu Metal Process (CMOS)
3.3-/1.8-/1.5-V I/Os, 1.25-/1.2-V Internal
Pin-Compatible with the TMS320C6455
Fixed-Point Digital Signal Processor
Copyright © 2006–2006, Texas Instruments Incorporated
TMS320C6454
2
C) Bus
