MOV OVC, loc16
MOV OVC, loc16
SYNTAX OPTIONS
MOV OVC, loc16
Operands
OVC
Description
Flags and
OVC
Modes
Repeat
Example
; Save and restore contents of ACC and OVC bits:
MOV
MOV
MOV
.
.
.
.
MOV
MOV
MOV
6-176
6-bit overflow counter
Load the overflow counter (OVC) with the upper 6 bits of the location pointed
to by the "loc16" addressing mode:
OVC = [loc16(15:10)];
The 6-bit overflow counter is modified.
This instruction is not repeatable. If this instruction follows the RPT
instruction, it resets the repeat counter (RPTC) and executes only once.
*SP++,OVC
; Save OVC on stack
*SP++,AL
; Save AL on stack
*SP++,AH
; Save AH on stack
AH,*−−SP
; Restore AH from stack
AL,*−−SP
; Restore AL from stack
OVC,*−−SP
; Restore OVC from stack
OPCODE
0101 0110 0000 0010
0000 0000 LLLL LLLL
Load the Overflow Counter
OBJMODE
RPT
1
CYC
1
