MOV AR6/7, loc16
MOV AR6/7, loc16
SYNTAX OPTIONS
MOV AR6, loc16
MOV AR7, loc16
Operands
AR6/7 AR6 or AR7, auxiliary registers
loc16
Description
Flags and
Modes
Repeat
6-160
0101 1110 LLLL LLLL
0101 1111 LLLL LLLL
Addressing mode (see Chapter 5)
Load AR6 or AR7 with the contents of the 16-bit location and leave the upper
16 bits of XAR6 and XAR7 unchanged:
AR6/7 = [loc16];
AR6/7H = unchanged;
None
This instruction is not repeatable. If this instruction follows the RPT
instruction, it resets the repeat counter (RPTC) and executes only once.
Load Auxiliary Register
OPCODE
OBJMODE
RPT
CYC
X
−
1
X
−
1
