Fuel Filter - SSANGYONG 1999 Musso Service Manual

FUEL FILTER

1 Fuel Filter
2 Outlet
Removal & Installation Procedure
1. Open the fuel tank cap and remove the fuel tank pressure.
2. Remove the fuel out (2) and in (3).
Installation Notice
Tightening Torque
3. Remove the mounting bracket bolt (4) and remove the fuel
filter (1).
Installation Notice
Tightening Torque
Notice
Place the fuel pump pad. There may be a corrosion due to
the contact between the fuel filter and the bracket.
4. Check for leaks by operating the engine.
Notice
Installation should follow the removal procedure in the
reverse order.
25 - 30 Nm
4 - 8 Nm
M161 ENGINE CONTROLS 1F2-57
3 Inlet
