SSANGYONG 1999 Musso Service Manual page 858

Shock Absorber.
1. Remove the lower mounting nut.
Installation Notice
Tightening Torque
2. Remove the upper mounting nut and remove the shock
absorber.
Installation Notice
Distance between the nut
end and the screw end
Tightening Torque
Upper Arm
1. Remove the upper arm fixing nut from the frame.
Installation Notice
Tightening Torque
2. Remove the upper arm fixing nut from the rear axle and
remove the upper arm.
Installation Notice
Tightening Torque
Lower arm
1. Remove the parking brake cable bracket.
50 - 65 Nm
6 - 9 mm
30 - 45 Nm
150 - 180 Nm
150 - 180 Nm
REAR SUSPENSION 2D-7
