1F3-28 OM600 ENGINE CONTROLS
Tools Required
001 589 65 09 00 Socket Wrench Insert
000 589 00 68 00 Cleaning Set

Repair Procedure

1. Clamp the nozzle holder (1) in a vice and remove the nozzle
tensioning nut (8).
Notice
Use protective jaws for clamping.
2. Disassemble the fuel injection nozzle.
3. Clean the nozzle needle (6) and nozzle body (7) with an
abradant.
4. Clean the nozzle seat with cleaning cutter.
5. Immerse nozzle needle (6) and nozzle body (7) in filtered
diesel fuel. When the nozzle body is held vertical, the weight
of the nozzle needle must cause it to slide down toward the
nozzle needle seat.
6. Assemble the injection nozzle so that the tip of the thrust
(4) pin is facing toward the nozzle holder.
Tightening Torque
Notice
Nozzle needle (6) and nozzle body (7) should always be
replaced as a pair.
Socket Wrench Insert 001 589 65 09 00
Cleaning Set 000 589 00 68 00
80 Nm
