3A-10 FRONT DRIVE AXLE
5. With part time transfer case.
5-1. Remove the cover mounting bolts and pull off the cover.
Installation Notice
Tightening Torque
5-2. Remove the snap ring of the drive shaft and pull off the
hub body.
Notice
For assembly, adjust the clearance between the snap ring
and hub not to exceed 0.2 mm (Shim thickness : 0.1, 0.2,
0.3, 0.5, 1.0 mm).
5-3. Remove the screws and pull off the locking hub washer.
Installation Notice
Tightening Torque
6. With full time transfer case
6-1. Detach the hub cap with screw driver and remove the
snap ring on drive shaft.
Installation Notice
Tightening Torque
Notice
For assembly, adjust the clearance between the snap ring
and hub not to exceed 0.2 mm (Shim thickness : 0.1, 0.2,
0.3, 0.5, 1.0 mm).
50 - 60 Nm
2 - 4 Nm
15 Nm
